Weight

1700kg

Lift platform height

18m

Working height:

20m

Dimension

3300*1450*2200MM

Working table：

The table panel is made of 4mm patterned steel plate

Security fence：

900mm（removable）

Lifting speed：

3-6 m/min

Strut material：

Tianjin silver cat brand aluminum alloy material

The hydraulic oil cylinder：

Ф50×6/set ,Drive and adjust the elevator to rise through an electric hydraulic pump

Dense sealing pieces：

Taiwan Dingji and O-ring

Electric machine：

AC 220V50HZ 2.2KW /1.1KW

Pump station：

Ningbo Tiandi hydraulic power unit

Chain：

Plate Chain LH0834

Bottom frame：

175*65*4mm high intensity Q235 Rectangular tubes.The legs are combined with 50 * 100 rectangular square tubes

Control style ：

Electric and up and down to control. Electronic integrated circuit board integrated box, remote control

Tires：

Wear resistant polyester wheel,Do not hurt the ground

Hydraulic oil：

32 # anti wear hydraulic oil is used in winter, and 46 # anti wear hydraulic oil is used in summer.　

Metal high-pressure hose:

Double layer high-pressure steel mesh rubber pipe.

Assisted self walking

Auxiliary self-propelled wheel, handle, motor, controller, battery: 85ah/12v * 2pcs maintenance free
